These beautiful color cutaway drawings are courtesy of Kyoshi Harada.
Visit Kyoshi's website for more 3D Tiger drawings as well as
drawings and cutaways of many different tanks, planes and ships.

The turret basket.	Left side of the hull showing ammunition storage and engine compartment.

The fold down commander's seat.	The loader's seat and the breech of the 88mm main gun.

Side view of the driver's compartment.	Rear view of the driver's compartment.

The radio operator's position showing the ball mounted machine gun.	Driveshaft, torsion bars and batteries.

The 8.8cm Kw.K. 36 L/56 main gun showing the gun sight and coaxial machine gun.

Rear view of the engine, cooling fans, radiators, water lines and fuel tanks.

Front view of the engine, cooling fans, radiators, fuel tanks and exhaust assemblies.
